Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine

Yixing Boyu Electric Power Machinery Co.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine from wholesalers

    Buy cheap Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine from wholesalers
    • Buy cheap Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine from wholesalers
    • Buy cheap Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine from wholesalers

    Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine

    Ask Lasest Price
    Brand Name : Boyu
    Model Number : TY2x40
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 100sets/month.
    Delivery Time : 15~25 days
    • Product Details
    • Company Profile

    Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine

    Hydraulic Tensioner Machine For Overhead Stringing Max Intermittent Pull 2x45kN


    Performance

    Bull-wheel diameter1300/1500mm
    Max conductor diameter40mm
    Groove number2x5
    Total weight5800kg
    Overall dimension (length*width*height)4300*2250*2700mm
    Max intermittent pull2x45kN
    Max continuous pull2x40kN
    Speed at max pull2.5km/h
    Max speed5km/h
    Pull at max speed2x20kN
    Max reverse pulling force2x35kN
    Max reverse pulling speed5km/h
    EngineCummins
    Hydraulic pumpGerman Rexroth/Dnish Danfoss
    Main motorGerman Rexroth/French Leduc
    Speed reducerGerman Rexroth
    Hydraulic meterGerman
    Operating handleGerman Rexroth
    Diesel77kw(103hp)
    Cooling systemwater
    Electrical system24V

    Overhead Stringing Max Intermittent Pull 2x45kN Hydraulic Tensioner Machine


    After-sale Service Warranty
    • The after-sale service is an important part of our marketing and sales work.
    • The quality of service provided will not only influence the company credit, but also closely relate to the safely running of the equipment.
    • In order to maintain the good reputation of BOYU, we will strictly observe relevant national regulations about Product-Quality Law and provide high quality products with the principle of hospitable reception, enthusiastic service, quick response and prompt resolution.
    We will conscientiously implement the after-sale service work in full-scale, and make commitment to our clients as follows:
    Training coursesCustomer support

    Get the best performance from BOYU machines

    Boyu is not a "simple manufacturer" - BOYU is Your best partner! Our Professional Group can offer their expertise by holding technical courses to all customers maximum one month time, and provide accommodation. From Operation to maintenance, BOYU technical training courses are also customized according to different levels of knowledge and to what kind of aim a customer would attain.

    Customer is our first priority

    We will provide some easily damaged parts of the equipment to ensure the normal operation.

    If any quality problems such as design, manufacture, function or procedure occur within the guarantee period, BOYU shall take full responsibility and bear all the economic losses incurred.

    If any other quality problems occurs within the guarantee period, BOYU shall provide online video service after receive the buyer’s notice in 24 hrs.

    If any big quality problems occurs out of the guarantee period, BOYU will also provide online video service after receive the buyer’s notice in 48 hrs.

    BOYU will provide a lifetime favorable price to the buyer with the materials and spare parts used in system operation, equipment maintenance, and guarantee 7days courier door by door.
