    Deutz Engine Transmission Line Stringing Equipment Hydraulic Puller Groove Number 7

    Ask Lasest Price
    Brand Name : Boyu
    Model Number : TY30D
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 100sets/month.
    Delivery Time : 15~25 days
    • Product Details
    • Company Profile

    Deutz Engine Transmission Line Stringing Equipment Hydraulic Puller Groove Number 7


    Transmission Line Stringing Equipment Deutz Engine Hydraulic Puller Groove Number 7


    Characteristics
    Bull-wheel diameter300mm
    Groove number7
    Max rope diameter13mm
    Applicable to the max connector diameter40mm
    Max diameter of rope reel1400mm
    Total weight2000kg
    Overall dimension (length*width*height)3200×1600×2000mm
    Structure stylesingle bridge trailer
    Performance
    Max pull35kN
    Rated pull30kN
    Corresponding Pulling Speed2.5km/h
    Corresponding Pulling Force15kN
    Engine
    Diesel56kw(73hp)
    Cooling systemair cooled
    Electrical system24V
    Main configuration
    EngineDeutz Air Cooled
    Hydraulic pumpDenmark Danfoss
    Hydraulic motorFrench HYDROLEDUC
    Speed reducerItaly BREVINI
    Main hydraulic valve partsGerman Rexroth/American SUN/Italy ATOS
    Tail frame winch motorDenmark Danfoss
    Hydraulic Transmission
    Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with a pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.


    Deutz Engine Transmission Line Stringing Equipment Hydraulic Puller Groove Number 7


    Company Profile

    Deutz Engine Transmission Line Stringing Equipment Hydraulic Puller Groove Number 7

    Jiangsu Province Yixing Boyu Electric Power Industry Company is located in west side of the beautiful and fertile Taihu Lake. Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:

    1. Electric power construction tools
    2. Nonmetallic galvanized the production equipment (Achieved high-tech products)
    3. Numerical control machine
    4. Low voltage no power-arc furnace compensation system
    Customer support

    Our contact person will do the best to deal with the problems our customers encountered, in order to ensure our customers' satisfaction and without any commitment from your side. An introduction course has been planned for all the customers that buy Boyu machines, we provide free technical support by means of phone or mail. Also our customers can download operation and maintenance videos from our website.

    1. We will provide some easily damaged parts of the equipment to ensure the normal operation.
    2. If any quality problems such as design, manufacture, function or procedure occur within the guarantee period, BOYU shall take full responsibility and bear all the economic losses incurred.
    3. If any other quality problems occurs within the guarantee period, BOYU shall provide online video service after receive the buyer’s notice in 24 hrs.
    4. If any big quality problems occurs out of the guarantee period, BOYU will also provide online video service after receive the buyer’s notice in 48 hrs.
    5. BOYU will provide a lifetime favorable price to the buyer with the materials and spare parts used in system operation, equipment maintenance, and guarantee 7days courier door by door.
