YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m

    Buy cheap YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m from wholesalers

    Buy cheap YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m from wholesalers
    • Buy cheap YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m from wholesalers
    • Buy cheap YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m from wholesalers

    YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m

    Ask Lasest Price
    Brand Name : BOYU
    Model Number : YL11-12x19
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 100000m/month.
    Delivery Time : 15~25 days
    • Product Details
    • Company Profile

    YL11 - 12x19 Anti Twist Wire Rope 80kN Steel Braided 1000m

    YL11-12x19 Anti Twist Wire Rope Anti-Twisting Steel Braided Rope


    Quick Details

    • Performance Item no.: YL11-12x19
    • Nominal Dia.: 11mm
    • Structure: 12 Strands
    • Breakage Tension: 80kN
    • Standard Length: 1000m
    • Dia. Of Reel: 1000mm
    • Total Weight: 454kg

    Anti Twist Wire Rope

    • Anti Twist Wire Rope with high strength hot dip galvanized steel quality air processed by the special process of special woven rope line.
    • Tension applied to pay-off power lines construction, lifting equipment with the balance shaft and the tail rope of mine, port and other major lift crane wire rope does not rotate when the required place.
    • It has high strength, good flexibility, corrosion rust-proof, not to fight the golden hook, and difficult to tie, long life and so on.
    Other Model
    Performance Item no.Nominal Dia.Breakage TensionStandard LengthStructureDia. Of ReelTotal Weight
    YL9-12x199mm55kN1000m12 Strands850mm294kg
    YL13-12x1913mm120kN1000m12 Strands1100mm642kg
    YL15-12X1915mm158kN1000m12 Strands1250mm886kg
    YL18-12X1918mm200kN1000m12 Strands1400mm1154kg
    YL22-12X29Fi22mm320kN800m12 Strands1400mm1258kg
    YL24-12X29Fi24mm360kN800m12 Strands1440mm1474kg
    YL28-12X29Fi28mm480kN500m12 Strands1600mm/
    YL20-18X1920mm252kN800m18 Strands1440mm1368kg
    YL22-18X29Fi22mm372kN500m18 Strands1440mm/
    YL24-18X29Fi24mm389kN500m18 Strands1600mm/
    YL28-18X29Fi28mm580kN500m18 Strands1600mm1655kg
    YL30-18X29Fi30mm658kN500m18 Strands1600mm1900kg
