TY1x40 Hydraulic Tensioner Machine For Overhead Line Diese Engine
77kw(103hp)
| TY1x40 Hydraulic Tensioner |
- Operated with 50kN tension machine, this machine is mainly applied
in hilly and flat lands for tension stringing of 500kV conductors,
and because of the great convenience brought by the reverse
traction function, it is the better choice for the construction in
small projects of transmission lines such as the modification works
of rural and urban networks.
|
| Characteristics |
| Bull-wheel diameter | 1300mm |
| Max conductor diameter | 40mm |
| Max Optical fiber cable diameter | 21mm |
| Groove width | 55mm |
| Groove number | 5 |
| Total weight | 2300kg |
| Overall dimension (length*width*height) | 3520*2000*1710mm |
| Performance |
| Max intermittent pull | 45kN |
| Max continuous pull | 40kN |
| Speed at max pull | 2.5km/h |
| Max speed | 5km/h |
| Pull at max speed | 20kN |
| Max reverse pulling force | 35kN |
| Main configuration |
| Engine | Cummins |
| Hydraulic pump | German Rexroth/Dnish Danfoss |
| Main motor | German Rexroth/French Leduc |
| Speed reducer | German Rexroth / Italy Brevini |
| Hydraulic meter | German |
| Operating handle | German Rexroth |
| Engine |
| Diesel | 77kw(103hp) |
| Cooling system | water |
| Electrical system | 24V |
Additional Devices
Lighting system for the trailer
Air brake system for the trailer(extra charge)
Hydraulic conductor clamps for drum change operations (extra
charge)
Swivel guide rope roller
Trailer for towing at max speed of 30 km/h
Digital speed and meter counter
Configuration
Hydraulic dynamometers
Hydraulic oil cooling system
Mechanical meter counters
Grounding connection point
Hydraulic power pack to control drum stands with hydraulic motor
Hydraulic Transmission
The machine can realize step less speed
The machine is provided with tension presetting system
Operation and Maintenance training
BOYU supply free operation and maintenance training in our factory,
and cover all cost of accommodation in our factory.
BOYU supply 3~5days engineering support for operation & maintenance
training on your work site, but you have to pay for the cost of
accommodation, transportation and round trip ticket.
After-sales service warranty
1) Our company have one year quality guarantee, if internal
components go wrong within one year, we will change another for
free.
2) Our company will provide some easily damaged parts of the
equipment to ensure the normal operation.
3) If any quality problems such as design, manufacture, function or
procedure occur within the guarantee period, our company shall take
full responsibility and bear all the economic losses incurred.
4) If any other quality problems occurs within the guarantee
period, Our company shall provide online video service after
receive the buyer's notice in 24 hrs.
5) If any big quality problems occurs out of the guarantee period,
our company will also provide online video service after receive
the buyer's notice in 48 hrs.
6) Our company will provide a lifetime favorable price to the buyer
with the materials and spare parts used in system operation,
equipment maintenance, and guarantee 7days courier door by door.
