    TY2x40 2x45kN Hydraulic Cable Tensioner Diesel Engine 77kw(103hp) Water Cooling System

    Ask Lasest Price
    Brand Name : BOYU
    Model Number : TY2x40
    Certification : ISO
    Payment Terms : L/C, T/T
    Supply Ability : 100sets/month.
    Delivery Time : 15~25 days
    Price : Negotiable
    • Product Details
    • Company Profile

    TY2x40 2x45kN Hydraulic Cable Tensioner Diesel Engine 77kw(103hp) Water Cooling System

    TY2x40 2x45kN Hydraulic Cable Tensioner Diesel Engine 77kw(103hp) Water Cooling System

    Characteristics
    Bull-wheel diameter: 1300/1500mm
    Max conductor diameter: 40mm
    Groove number: 2x5
    Total weight: 5800kg
    Overall dimension (length*width*height): 4300×2250×2700mm
    Performance
    Max intermittent pull: 2x45kN
    Max continuous pull: 2x40kN
    Speed at max pull: 2.5km/h
    Max speed: 5km/h
    Pull at max speed: 2x20kN
    Max reverse pulling force: 2x35kN
    Max reverse pulling speed: 5km/h
    Engine
    Diesel: 77kw(103hp)
    Cooling system: water
    Electrical system: 24V
    Main configuration
    Engine: Cummins
    Hydraulic pump: German Rexroth/Dnish Danfoss
    Main motor:German Rexroth/French Leduc
    Speed reducer: German Rexroth
    Hydraulic meter: German
    Operating handle: German Rexroth
    Hydraulic Transmission
    The machine can realize step less speed.
    The machine is provided with tension presetting system.
    Configuration
    Hydraulic dynamometers
    Hydraulic oil cooling system
    Digital speed and meter counter
    Hydraulic front stabilizer
    Grounding connection point
    Hydraulic power pack to control up to 2 separated drum stands with hydraulic motor
    Additional Devices
    Lighting system for the trailer
    2 hydraulic rope/conductor clamp(extra charge)
    Swivel guide rope roller
    Trailer for towing at max speed of 30 km/h
    Digital speed and meter counter


    TY2x40 2x45kN Hydraulic Cable Tensioner Diesel Engine 77kw(103hp) Water Cooling System

    Company Profile
    TY2x40 2x45kN Hydraulic Cable Tensioner Diesel Engine 77kw(103hp) Water Cooling System

    Company Profile

    Our company is located in Yixing City, Jiangsu Province with a total area of ​​42,800 square meters and more than 160 employees.
    Our company is a high-tech enterprise in Jiangsu Province and has six patents, two of which are invention patents.
    Our company has formed four series of products:

    1: Electric power construction tools

    2: Nonmetallic galvanized the production equipment (Achieved high-tech products)

    3: Numerical control machine

    4: Low voltage no power-arc furnace compensation system

    Boyu's history

    Our company was established in 1994
    Our company passed ISO9001 certification in 2001 and obtained AAA certificate at the same time

    In 2006 attains the Wuxi city contract trustworthiness enterprise, also achieved famous brand product in Wuxi city

    In 2007 attains the high-tech enterprise of Jiangsu province, also achieved brand-name products in Jiangsu province
    In 2009, won a major achievement award in Wuxi City
    In 2010, Boyu cooperated with the famous German Caesars company and founded the Boset brand
    Our company obtained the National Science and Technology Innovation Program Project in 2010.
    As of November 8, 2010, Boyu has successfully sold nearly 4,000 sets of pullers and tensioning equipment (excluding mobile ground grinding). Our products are sold well in Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico,Germany.
