20kn - 30kN Cradle Reel Elevators Welded Steel For Tension Stringing

Quick details:
1. Transmission Line Stringing Equipment Accessories & Tools
2. Cradle Reel Elevator
3. Reel Diameter: 1400, 1900
4. Rated Load: 20~30kN
5. Welded Steel with protective coating

6. Boyu Brand

Description:
The Cradle reel elevators are made of welded steel with a protective coating. It is suitable to string traction rope and guide rope, with a disc brake, it have 0-150kg tension, can be used for tension stringing, when you stop to string, the reel will be stopped automatically.

Specification:

Model	Dimensions (mm)					Capacity	Mass
	A	B	C	D min	D max	(kN)	(kg)
TYCVC-002	2550	1325	1060	1100	1400	20	81
TYCVC-201	3020	1060	1130		1900	26	150
TYCVC-004	2015	1442	1380		1400	30	390

Maufacturer Introduction
Yixing Boyu Electric Power Machinery Company is located in west side of the beautiful and fertile Taihu Lake. We are at the east of China, near Shanghai, Nanjin, Hangzhou City, about 2~3 hours by car.

Established in 1994, Yixing Boyu Electric Power Machinery Co., Ltd. is a manufacturer specialized in the research, development and production of Electric Power Machinery.
We are located in beautiful and rich city: Yixing city. We are a High-tech enterprise in Jiangsu Province, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
　　1. Main configurations of our machine are from Germany and USA
　　Engine: American Cummins
　　Main pump: German Rexroth
　　Main motor& speed reducer: German Rexroth
　　Tail bracket hoisting motor: American Eton
　　Hydraulic meter: German
　　2. Our company was founded in 1994, having 27 years rich experience in this field. Our product sells in distant markets: Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc. Our product is also very popular in china.
　　3. We have one year quality guarantee, if internal components go wrong within one year, we will change another for free.
　　4. We can supply the specific components to the buyers with cost price after warranty period.



TYCVC Cradle Reel Elevators Reel Stands Reel Supports Transmission Line Stringing Tools Accessories

Established in 1993, Yixing Boyu Electric Power Machinery Co., Ltd. is a manufacturer specialized in the research, development and production of Electric Power Machinery, CE certified.

We are located in beautiful and rich city: Yixing city. We are a High-tech enterprise in Jiangsu Province, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

    1. Main configurations of our machine are from Germany and USA

• Engine: American Cummins
• Main pump: German Rexroth
• Main motor& speed reducer: German Rexroth
• Tail bracket hoisting motor: American Eton
• Hydraulic meter: German

    2. Our company have more than 25 years rich experience in this field. Our product sells in distant markets: Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc. Our product is also very popular in china.

    3. We have one year quality guarantee, if internal components go wrong within one year, we will change another for free.

    4. We can supply the specific components to the buyers with cost price after warranty period.
