Max Intermittent Pull 4Tons 40kN 110kv Transmission Line Stringing
Equipment Main Pump German Rexroth TY40
Quick details:
- 110kv Tansmission Line Stringing Equipment
- Max rope diameter: 16mm
- Hydraulic Puller
- Max pull: 40kN 4Tons
- Diesel: Cummins 77kw 103hp
- Max reel size: 1200mm
- Main pump and motor: German Rexroth
- Tail bracket hoisting motor: American Eton
- Boyu Brand
Performance
1.Max intermittent pull: 40kN
2.Max continuous pull: 30kN
3.Speed at max pull: 2.5km/h
4.Max speed: 5km/h
5.Pull at max speed: 20kN
Engine
- Diesel 77kw 103hp
- Cooling system: water
- Electrical system: 24V
Description
Together with tension machine, this model allows for the tension
stringing of 220kV lines in mountainous and hilly areas and can be
used for the traction stringing of OPGW or ADSS cable in various
terrains.
Characteristics
- Bull-wheel diameter: 400mm
- Groove number: 7
- Max rope diameter : 16mm
- Max diameter of rope reel: 1200mm
- Total weight: 3000kg
- Overall dimension (length*width*height): 3600×2100×2200mm
Main configuration
- Engine: Cummins
- Main pump: German Rexroth
- Main motor speed reducer: German Rexroth
- Tail bracket hoisting motor: American Eton
- Hydraulic meter: German
- Operating handle: German Rexroth
Configuration
- Hydraulic dynamometer with set-point and automatic control of
maximum pull
- Hydraulic oil cooling system
- Control instruments for hydraulic system and diesel engine
- On board reel winder with automatic level wind, suitable for
standard reel mod. 1100 and 1200
- Manual front stabilizer
- Grounding connection point
Hydraulic Transmission
Closed hydraulic circuit for step less speed variation in both
rotating directions. This machine is provided with a pull
pro-setting system that maintains the pre-set pulling value (also
when the speed is reduced to "0") by automatically adjusting the
operation speed according to the friction and unexpected loads
which may occur.
Additional Devices
- Lighting system for the trailer
- Hydraulic rope clamp for reel change(extra charge)
- Swivel guide rope roller
- Trailer for towing at max speed of 30 km/h
- Extra shaft
- Digital speed and meter counter
Customers
More pictures
Company Introduction
Established in 1994, Yixing Boyu Electric Power Machinery Co., Ltd.
is a manufacturer specialized in the research, development and
production of Electric Power Machinery.
We are located in beautiful and rich city: Yixing city. We are a
High-tech enterprise in Jiangsu Province, with convenient
transportation access. All of our products comply with
international quality standards and are greatly appreciated in a
variety of different markets throughout the world.
1. Main configurations of our machine are from Germany and USA
Engine: American Cummins
Main pump: German Rexroth
Main motor& speed reducer: German Rexroth
Tail bracket hoisting motor: American Eton
Hydraulic meter: German
2. Our company was founded in 1994, having 27 years rich
experience in this field. Our product sells in distant markets:
Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc.
Our product is also very popular in china.
3. We have one year quality guarantee, if internal components go
wrong within one year, we will change another for free.
4. We can supply the specific components to the buyers with cost
price after warranty period.
Work site
Max Intermittent Pull 4Tons 40kN 110kv Transmission Line Stringing
Equipment Main Pump German Rexroth TY40
TY40 Hydraulic Puller Together with tension machine, this model allows for the tension
stringing of 220kV lines in mountainous and hilly areas and can be
used for the traction stringing of OPGW or ADSS cable in various
terrains. |
Characteristics Bull-wheel diameter: 400mm Groove number: 7 Max rope diameter : 16mm Max diameter of rope reel: 1200mm Total weight: 3000kg Overall dimension (length*width*height): 3600×2600×2200mm | Performance Max intermittent pull: 40kN Max continuous pull: 30kN Speed at max pull: 2.5km/h Max speed: 5km/h Pull at max speed: 20kN |
Engine Diesel 77kw(103hp) Cooling system water Electrical system 24V |
Main configuration Engine: Cummins hydraulic pump: German Rexroth Main motor: German Rexroth speed reducer: German Rexroth Tail bracket hoisting motor: American Eton Hydraulic meter: German Operating handle: German Rexroth | Hydraulic Transmission Closed hydraulic circuit for step less speed variation in both
rotating directions. This machine is provided with a pull
pro-setting system that maintains the pre-set pulling value (also
when the speed is reduced to "0") by automatically adjusting the
operation speed according to the friction and unexpected loads
which may occur. |
Configuration Hydraulic dynamometer with set-point and automatic control of
maximum pull Hydraulic oil cooling system Control instruments for hydraulic system and diesel engine On board reel winder with automatic level wind, suitable for
standard reel mod. 1100 and 1200 Mechanical front stabilizer Grounding connection point | Additional Devices Lighting system for the trailer Hydraulic rope clamp for reel change Swivel guide rope roller Trailer for towing at max speed of 30 km/h Extra shaft Digital speed and meter counter (extra charge) |
