Max Pull 140kN 14T Overhead Line Stringing Equipment Single
Conductor Hydraulic Puller Tensioner TY140TP
Quick details:
Overhead Line Stringing Equipment
Hydraulic Puller Tensioner
Main pump and motor: German Rexroth
Speed Reducer: German Rexroth
Max pull: 140kN
Diesel: Cummins 129kw(173hp)
Main pump and motor: German Rexroth
Speed Reducer: German Rexroth
Bull-wheel diameter: 1500mm
Max rope diameter: 24mm
Max conductor diameter: 40mm
Boyu Brand
Description
The machine is suitable to string one, two, three or four ropes or
bundled conductors. The bull-wheel grooves are made of high
resistance interchangeable nylon sectors. The machine is completely
electronically controlled.
Main configuration
Engine: Cummins
Main pump: German Rexroth
Main motor speed reducer: German Rexroth
Hydraulic meter: German
Operating handle: German Rexroth
Performance
Max pull
Max pull: 140kN
Speed at max pull: 1.7km/h
Max speed: 4km/h
Pull at max speed: 60kN
Max tension
Max Tension: 140kN
Max Speed: 4km/h
Engine
Diesel 129kw(173hp)
Cooling system water
Electrical system 24V
Characteristics
Bull-wheel diameter: 1500mm
Max rope diameter : 24mm
Max conductor diameter: 40mm
Total weight: 6800kg
Overall dimension (length*width*height): 4700×2300×2700mm
Configuration
2 negative self-acting hydraulic brakes
2 hydraulic dynamometers with set-point and automatic control of
maximum pull
Hydraulic oil cooling system
Digital meter counters
Control instruments for hydraulic system and diesel engine
Rigid axles for towing at max speed of 30km/h with mechanical
parking brake
Hydraulic power pack to control up to 2 reel stands with hydraulic
head or 2 reel winders with independent controls
Hydraulic front stabilizer
Grounding connection point
Hydraulic Transmission
Closed hydraulic circuit for step less speed variation in both
rotating directions. This machine is provided with 2 pull
pro-setting system that maintains the pre-set pulling value (also
when the speed is reduced to "0") by automatically adjusting the
operation speed according to the friction and unexpected loads
which may occur.
Additional Devices
Lighting system for the trailer
Hydraulic brake system for the trailer (extra charge)
2 hydraulic conductor clamps for drum change
operations (extra charge)
Electronic pull and speed recorder
Customers Visiting
Company Introduction
Jiangsu Province Yixing Boyu Electric Power Machinery Company is
located in west side of the beautiful and fertile Taihu Lake.
Established in 1994, Yixing Boyu Electric Power Machinery Co., Ltd.
is a manufacturer specialized in the research, development and
production of Electric Power Machinery.
We are located in beautiful and rich city: Yixing city. We are a
High-tech enterprise in Jiangsu Province, with convenient
transportation access. All of our products comply with
international quality standards and are greatly appreciated in a
variety of different markets throughout the world.
1. Main configurations of our machine are from Germany and USA
Engine: American Cummins
Main pump: German Rexroth
Main motor& speed reducer: German Rexroth
Tail bracket hoisting motor: American Eton
Hydraulic meter: German
2. Our company was founded in 1994, having 27 years rich
experience in this field. Our product sells in distant markets:
Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc.
Our product is also very popular in china.
3. We have one year quality guarantee, if internal components go
wrong within one year, we will change another for free.
4. We can supply the specific components to the buyers with cost
price after warranty period.
