Tensioning 9T Overhead Line Stringing Equipment for Electrical Transmission Line

90kN 9T Overhead Line Stringing Equipment Dual Purpose Machine Puller Tensioner TY90TP

Quick details:
Overhead Line Stringing Equipment
Hydraulic Puller Tensioner Dual Purpose Machine
Max pull: 90kN
Diesel: Cummins 118kw(158hp)
Main pump and motor: German Rexroth
Speed Reducer: German Rexroth
Bull-wheel diameter: 1500mm
Max rope diameter: 18mm
Max conductor diameter: 40mm

Boyu Brand

Description
The machine is suitable to string one or two ropes or bundled conductors. The bull-wheel grooves are made of high resistance interchangeable nylon sectors. The machine is completely electronically controlled.

Performance
Max pull
Max pull: 90kN
Speed at max pull: 2.4km/h
Max speed: 5km/h
Pull at max speed: 44kN
Max tension
Max Tension: 90kN
Max Speed: 5km/h

Engine
Diesel 118kw(158hp)
Cooling system water
Electrical system 24V

Characteristics
Bull-wheel diameter: 1500mm
Max rope diameter : 18mm
Max conductor diameter: 40mm
Total weight: 4600kg
Overall dimension (length*width*height): 4700×2300×2700mm

Main configuration
Engine: Cummins
Main pump: German Rexroth
Main motor speed reducer: German Rexroth

Operating handle: German Rexroth
Hydraulic meter: German

Configuration
Negative self-acting hydraulic brakes
Hydraulic dynamometers with set-point and automatic control of maximum pull
Hydraulic oil cooling system
Digital meter counters
Control instruments for hydraulic system and diesel engine
Rigid axles for towing at max speed of 30km/h with mechanical parking brake
Hydraulic power pack to control up to 2 reel stands with hydraulic head or 2 reel winders with independent controls
Hydraulic front stabilizer
Grounding connection point

Hydraulic Transmission
Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with 2 pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.

Additional Devices
Lighting system for the trailer
Hydraulic brake system for the trailer(extra charge)
2 hydraulic conductor clamps for drum change
operations (extra charge)
Electronic pull and speed recorder

Company Introduction
Jiangsu Province Yixing City, Yixing Boyu Electric Power Machinery Company is located in west side of the beautiful and fertile Taihu Lake.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:

Overhead transmission line stringing equipment and accessories and tools.
Nonmetallic galvanized the production equipment (Achieved high-tech products)
Numerical control machine
Low voltage no power-arc furnace compensation system

We produce 40~60sets of stringing equipment each month and all kinds of accessories.
